    HPS 59801

    Porosity Sealant (HPS) 59801 is a low viscosity liquid sealant designed for sealing interfacial leak paths in flexible electronic assemblies. It may also be used to enhance dielectric strength or seal porosity in passive materials. The dual-cure system incorporated in HPS 59801 offers the advantage of elevated temperature curing or curing at room temperature. HPS 59801 is typically applied with a vacuum impregnation process that removes air from the internal void and then saturates the part with liquid sealant. In the absence of circulating air, the liquid rapidly polymerizes to form a tough, flexible, thermoset polymer that permanently seals gaps in the assembly. Excess liquid sealant is rinsed from the outside of the part with an aqueous solution effectively leaving no surface build up. Parts processed with HPS 59801 are sealed internally but remain cosmetically and dimensionally unchanged. Typical applications include sealing or unitizing over-molded electrical components against leakage of air, water, coolants, oils and other fluids. As a good insulator, HPS 59801 may also be used to improve the dielectric strength across gaps between high voltage conductors.
    SKU: 59801PT
    *
    Products specifications
    Substrates Wood
    Substrates Magnets
    Substrates Rubber
    Substrates Glass
    Substrates Plastic
    Substrates Stone
    Substrates Metal
    Substrates Composite
    Applications Impregnation
